HERTZ HSP3 SP4.900 AMPLIFIER SX165NEO SX690NEO SPEAKERS WIRES SADDLE

 Brand New!
pkg - Hertz MPX-690.3 6X9" 3-Way Speakers + HD14H Harley Davidson Saddlebag Lid Kit & Speaker Harness

 Features & Specifications:
HSP3

• Hertz HSP3 Plug and Play 4 Speaker Kit with Saddlebag 6x9 Kit - includes: SP4.900 amp, SX165 NEO Coax Speakers, SX690 NEO Coax Speakers, HTHP14 T-Power Harness and HD14H Saddlebag Lid Kit with HBH14 Speaker Harness - Includes the Hertz SPL Show SP 4.900 D-Class 4 Channel Amplifier 250 WRMS x 4 at 2Ω (IP55 rated), Hertz SPL Show Series SX-165-NEO 6.5" Two-Way SPL Coaxial Speakers with Neo Magnets and UV/Waterproofing (Pair), Hertz SPL Show Series SX-690-NEO 6x9" Three-Way SPL Coaxial Speakers with Neo Magnets and UV/Waterproofing, Hertz HD14H Saddle Bag Lid Kit with Speaker Harness includes: HD14 Saddlebag Lid Kit and HBH14 Speaker Harness and Hertz HTHP14 T-Power Harness.

SP 4.900Ch: 4 - 3 - 2 | 1000 WSP 4.900 is the first Hertz amplifier featuring the renewed Hertz ADC (Advanced D-Class) output stage, reaching up to 85% efficiency and delivering an impressive power rating of 160 x 4 (4Ω) W RMS or 500 W x 2 (4Ω) W RMS when bridged, with an ultra-compact size of 211.6 (8.3) x 130 (5.1) mm (in.). Being ultra-compact with impressive power, SP 4.900 is the ideal choice for Motorcycle application and for under-seat in sports cars and behind-seat installations in trucks.  Features

• Up to 87% efficiency thanks to ADC (Advanced D-Class) output stage.
• USS (Universal Speakers Simulators) allows SP 4.900 to work with head units featuring the “speaker load detection” circuit.
• 160 W RMS x 4 (4Ω) with ultra-compact size 211.6 x 130 x 49 / 8.3 x 5.1 x 1.9 (mm/inch).
• IP55 aluminium chassis for maximum protection against humidity and external agents.
• No cooling fan to prevent internal accumulation of dirt 6. Sealed power cord, line inputs, and speaker outputs to prevent oxidation.
• Crossovers filters and controls on a single side to facilitate calibration when the product is installed.

 General SpecsChannels4 - 3 - 2Nominal power supply voltage11 ÷ 15 VDCPulse Operating voltage6 ÷ 16 VDCIdling current1.1 AIdling current when off0.03 mAConsumption @ 14.4 VDC, MIN load impedance (Max Musical Power)50 ARemote IN6 ÷ 15 VDC (9 mA)DC-REM - Remote Turn on by SPK DC from OUTPUT BTL speakers3.5 ÷ 7 VDCDistortion - THD @ 1 kHz, 4Ω, 70% Rated Power0.02%Damping factor @ 1 kHz, 4Ω, 2 VRMS200Bandwidth @ -3 dB10 Hz ÷35 kHzS/N ratio (A weighted @ 1 V Input)105 dBAPre-In sensitivity0.6 ÷ 6 VRMSSpeaker-In sensitivity2.2 ÷ 22 VRMSMinimum load impedance: @ 4Ch2Ω@ 3Ch2Ω + 2Ω + 4Ω@ 2Ch4ΩIP RatingIP55Operating Temperature Range0°C (32°F) to 55°C (131°F)Max size (mm/inch)211.6 x 130 x 49 / 8.33 x 5.118 x 1.929Weight (kg/lbs)2.15 / 4.74Adjustable Crossoversyes Output PowerOutput Nominal Power (RMS) @ 14.4 VDC, THD 1%: 4 Ch:160 W x 4 (4Ω)4 Ch:250 W x 4 (2Ω)3 Ch:160 W x 2 (4Ω) + 500 W x 1 (4Ω)3 Ch:250 W x 2 (2Ω) + 500 W x 1 (4Ω)2 Ch:500 W x 2 (4Ω)Total Power1000 W  SX 690.1 NEOin. 6 x 9 mm (in.) | Spl Coaxial | 260 W | 4 Ohm

SX 690.1 NEO is a real beast with a Hi-SPL Mid-Hi unit based on a 1.4” dome tweeter and 1” dome super tweeter with a resettable solid-state protection circuit. Cone is made with nature-proof high stiffness pressed paper featuring innovative water/humidity resistance and anti-UV treatments. The double-layer copper voice coil wound on polyimide former ensures unparalleled power handling. New motors units are made of special Neodymium N38 H to obtain a minimum bulk and increased performance.

The provided MPG 690 grille is made of a high-resistance ABS plastic structure with a metallic finish combined with a protective metal mesh.



Features

• Nature-proof high stiffness pressed-paper cone featuring innovative water/ humidity resistant and anti-UV treatments.
• Durable Extreme SPL performance in a compact size & light-weight thanks to the N38 H Neodymium grade magnet.
• Unparalleled power handling delivered by the double-layer copper voice coil, wound on polyimide former.
• Hi-SPL Mid-Hi unit based on 1.4” dome tweeter and 1” dome super tweeter with resettable solid-state tweeter protection circuit.
• Double faston terminals allow daisy-chaining of multiple units and provide compatibility with the most common motorcycle connections.
• Provided elegant grille made with a high-resistance ABS plastic structure with a metallic finish combined with a protective metal mesh.

 Technical SpecsComponentSPL COAXIALSize mm (in.)in. 6 x 9Power Handling - Continuous W130Power Handling - Peak W260Impedance Ohm4Tweeter diaphragm mm (in.)29 (1.14)Woofer Voice Coil Ø mm (in.)38 (1.5)Tweeter Voice Coil Ø mm (in.)25 (1)Frequency Response Hz65 ÷ 24kWoofer Magnet size D x d x h mm (in.)110 x 45 x 20 (4.33 x 1.77 x 0.79)Tweeter Magnet size D x h mm (in.)24,5 x 6 x 3,5 (0.96 x 0.24 x 0.14)Weight of one speaker kg (lb.)1,69 (3.73)Woofer MagnetSpecial Neodymium N38 HTweeter MagnetSpecial Neodymium N38 HConeWater repellent pressed paperDomeTetolon Electro-acoustic Specs
D mm169Xmax mm5,5Re Ohm3Fs Hz65Le mH0,4Vas I11,29Mms g36,1Cms mm/N0,16BL T*m7,665Qts0,62Qes0,78Qms2,9Spl dB94  Shipping Policy:
